Universal U-Series Mounted Offset Disc Harrow Technical Specifications
Universal U-Series Mounted Offset Disc Harrow Features
Brand
Model
U-Series Mounted Offset Disc Harrow
Category
No. of Discs
16 to 20
Type
Weight
570-680 Kg
Suitable HP
50-75 HP
Gang Bolt
Solild Square 32 (Rod)
Type of Disc
Boron Steel/High Carbon Steel and Plain /Notched Disc(optional)
Disc Diameter
508-560 mm
Distance Between Discs
228 mm
Bearing Hub
6 to 8
Width of Cut
1852-2285 mm
Price
Data Last Updated On: 27 Jul 2026
About Universal U-Series Mounted Offset Disc Harrow
Universal U-Series Mounted Offset Disc Harrow Models
| Specification | BEUSMODH-16 | BEUSMODH-18 | BEUSMODH- 20 |
|---|---|---|---|
| Weight | 570 kg | 640 kg | 680 kg |
| gang bolt | Solid Square 32 (Rod) | Solid Square 32 (Rod) | Solid Square 32 (Rod) |
| No. of Disc | 16 | 18 | 20 |
| Type of Disc | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) |
| Disc Diameter | 508-560 mm | 508-560 mm | 508-560 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 6 | 8 | 8 |
| Width of Cut | 1852 mm | 2068 mm | 2285 mm |
| Tractor HP | 50-55 HP | 60-65HP | 70-75 HP |
U-Series Mounted Offset Disc Harrow - BEUSMODH-16
Weight
570 kg
gang bolt
Solid Square 32 (Rod)
No. of Disc
16
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
508-560 mm
Distance Between Discs
228 mm
Bearing Hub
6
Width of Cut
1852 mm
Tractor HP
50-55 HP
U-Series Mounted Offset Disc Harrow - BEUSMODH-18
Weight
640 kg
gang bolt
Solid Square 32 (Rod)
No. of Disc
18
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
508-560 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2068 mm
Tractor HP
60-65HP
U-Series Mounted Offset Disc Harrow - BEUSMODH- 20
Weight
680 kg
gang bolt
Solid Square 32 (Rod)
No. of Disc
20
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
508-560 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2285 mm
Tractor HP
70-75 HP
