Farmking Compact Disc Harrow Technical Specifications
Farmking Compact Disc Harrow Features
Brand
Model
Compact Disc Harrow
Category
Working Width
1912-2562 mm
No. of Discs
16 to 22
Type
Weight
718-975 Kg
Suitable HP
50-90 HP
Gang Bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front
Disc Diameter
560-610 mm
Distance Between Discs
228 mm
Bearing Hub
6 to 8
Price
Data Last Updated On: 27 Jul 2026
About Farmking Compact Disc Harrow
Farmking Compact Disc Harrow Models
| Specification | FKCDH-16D | FKCDH-18D | FKCDH-20D | FKCDH-22D |
|---|---|---|---|---|
| Working Width | 1912 mm | 2128 mm | 2345 mm | 2562 mm |
| Working Depth | 228 mm | 228 mm | 228 mm | 228 mm |
| Weight | 718 kg | 825 kg | 890 kg | 975 kg |
| gang bolt | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) |
| No. of Disc | 16 | 18 | 20 | 22 |
| Type of Disc | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) |
| Disc Diameter | 560 mm | 560 mm | 560 mm | 560 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 6 | 8 | 8 | 8 |
| Width of Cut | 1912 - 2562 mm | 1912 - 2562 mm | 1912 - 2562 mm | 1912 - 2562 mm |
| Tractor HP | 50 - 60 HP | 60 - 70 HP | 70 - 80 HP | 80 - 90 HP |
Compact Disc Harrow - FKCDH-16D
Working Width
1912 mm
Working Depth
228 mm
Weight
718 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
16
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Bearing Hub
6
Width of Cut
1912 - 2562 mm
Tractor HP
50 - 60 HP
Compact Disc Harrow - FKCDH-18D
Working Width
2128 mm
Working Depth
228 mm
Weight
825 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
18
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
1912 - 2562 mm
Tractor HP
60 - 70 HP
Compact Disc Harrow - FKCDH-20D
Working Width
2345 mm
Working Depth
228 mm
Weight
890 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
20
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
1912 - 2562 mm
Tractor HP
70 - 80 HP
Compact Disc Harrow - FKCDH-22D
Working Width
2562 mm
Working Depth
228 mm
Weight
975 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
22
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
1912 - 2562 mm
Tractor HP
80 - 90 HP
