Universal Poly Disc Harrow Technical Specifications
Universal Poly Disc Harrow Features
Brand
Model
Poly Disc Harrow
Category
No. of Discs
5 to 10
Type
Suitable HP
40-110 HP
Gang Bolt
Dia 60mm C- class pipe with solid Rod
Type of Disc
Boron Steel/High Carbon Steel and Plain /Notched Disc(optional)
Disc Diameter
560x4T-610x4.5T mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos (heavy duty)
Width of Cut
952-2206 mm
Price
Data Last Updated On: 27 Jul 2026
About Universal Poly Disc Harrow
Universal Poly Disc Harrow Models
| Specification | BEPDH-5 | BEPDH-6 | BEPDH-7 | BEPDH-8 | BEPDH-9 | BEPDH-10 |
|---|---|---|---|---|---|---|
| Weight | 320 kg | 370 kg | 425 kg | 480 kg | 545 kg | 600 kg |
| gang bolt | Dia. 60 mm C-Class Pipe with Solid Rod | Dia. 60 mm C-Class Pipe with Solid Rod | Dia. 60 mm C-Class Pipe with Solid Rod | Dia. 60 mm C-Class Pipe with Solid Rod | Dia. 60 mm C-Class Pipe with Solid Rod | Dia. 60 mm C-Class Pipe with Solid Rod |
| No. of Disc | 5 | 6 | 7 | 8 | 9 | 10 |
| Type of Disc | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) | Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional) |
| Disc Diameter | 560-660 mm | 560-660 mm | 560-660 mm | 560-660 mm | 560-660 mm | 560-660 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 2 Nos. (Heavy Duty) | 2 Nos. (Heavy Duty) | 2 Nos. (Heavy Duty) | 2 Nos. (Heavy Duty) | 2 Nos. (Heavy Duty) | 2 Nos. (Heavy Duty) |
| Width of Cut | 952 mm | 1202 mm | 1453 mm | 1704 mm | 1955 mm | 2206 mm |
| Tractor HP | 40-45 HP | 50-55 HP | 60-65 HP | 70-75 HP | 80-90 HP | 95-110 HP |
Poly Disc Harrow - BEPDH-5
Weight
320 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
5
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
952 mm
Tractor HP
40-45 HP
Poly Disc Harrow - BEPDH-6
Weight
370 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
6
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
1202 mm
Tractor HP
50-55 HP
Poly Disc Harrow - BEPDH-7
Weight
425 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
7
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
1453 mm
Tractor HP
60-65 HP
Poly Disc Harrow - BEPDH-8
Weight
480 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
8
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
1704 mm
Tractor HP
70-75 HP
Poly Disc Harrow - BEPDH-9
Weight
545 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
9
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
1955 mm
Tractor HP
80-90 HP
Poly Disc Harrow - BEPDH-10
Weight
600 kg
gang bolt
Dia. 60 mm C-Class Pipe with Solid Rod
No. of Disc
10
Type of Disc
Boron Steel/High Carbon Steel and Plain Rear/Front Notched Disc (Optional)
Disc Diameter
560-660 mm
Distance Between Discs
228 mm
Bearing Hub
2 Nos. (Heavy Duty)
Width of Cut
2206 mm
Tractor HP
95-110 HP
