Farmking Trailed Disc Harrow Technical Specifications
Farmking Trailed Disc Harrow Features
Brand
Model
Trailed Disc Harrow
Category
Working Width
1410-2105 mm
Type
Weight
340-580 Kg
Suitable HP
35-75 HP
Gang Bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front
Disc Diameter
560-610 mm
Distance Between Discs
228 mm
Price
Data Last Updated On: 27 Jul 2026
About Farmking Trailed Disc Harrow
Farmking Trailed Disc Harrow Models
| Specification | FKDHUF-14D | FKDHUF-16D | FKDHUF-18D | FKDHUF-20D |
|---|---|---|---|---|
| Working Width | 1410 mm | 1635 mm | 1870 mm | 2105 mm |
| Working Depth | 150 mm | 150 mm | 150 mm | 150 mm |
| Weight | 340 kg | 360 kg | 400 kg | 580 kg |
| gang bolt | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) |
| No. of Disc | 14-20 | 14-20 | 14-20 | 14-20 |
| Type of Disc | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) |
| Disc Diameter | 560 mm | 560 mm | 560 mm | 560 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Tractor HP | 35 - 40 HP | 40 - 50 HP | 50 - 60 HP | 60 - 75 HP |
Trailed Disc Harrow - FKDHUF-14D
Working Width
1410 mm
Working Depth
150 mm
Weight
340 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
14-20
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
35 - 40 HP
Trailed Disc Harrow - FKDHUF-16D
Working Width
1635 mm
Working Depth
150 mm
Weight
360 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
14-20
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
40 - 50 HP
Trailed Disc Harrow - FKDHUF-18D
Working Width
1870 mm
Working Depth
150 mm
Weight
400 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
14-20
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
50 - 60 HP
Trailed Disc Harrow - FKDHUF-20D
Working Width
2105 mm
Working Depth
150 mm
Weight
580 kg
gang bolt
32 mm (Solid Square Rod)
No. of Disc
14-20
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
60 - 75 HP
