Farmking Mounted Disc Harrow Technical Specifications
Farmking Mounted Disc Harrow Features
Brand
Model
Mounted Disc Harrow
Category
Working Width
1420-2068 mm
Tractor Power (HP)
35-75 HP
Type
Weight
340-580 kg
Suitable HP
35-75 HP
Gang Bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front (optional)
Disc Diameter
560-610 mm
Distance Between Discs
228-254 mm
Width of Cut
1210 -1830 mm
Price
Data Last Updated On: 27 Jul 2026
About Farmking Mounted Disc Harrow
Farmking Mounted Disc Harrow Models
| Specification | FKDHUF-12D | FKDHUF-14D | FKDHUF-16D | FKDHUF-18D |
|---|---|---|---|---|
| Working Width | 1420 mm | 1635 mm | 1835 mm | 2068 mm |
| Working Depth | 150 mm | 150 mm | 150 mm | 150 mm |
| Weight | 340 kg | 360 kg | 400 kg | 500 kg |
| gang bolt | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) | 32 mm (Solid Square Rod) |
| Type of Disc | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) | Plain Disc / Notched in Front (Optional) |
| Disc Diameter | 560 mm | 560 mm | 560 mm | 560 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm | 228 mm |
| Tractor HP | 35 - 40 HP | 40 - 50 HP | 50 - 60 HP | 60 - 75 HP |
Mounted Disc Harrow - FKDHUF-12D
Working Width
1420 mm
Working Depth
150 mm
Weight
340 kg
gang bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
35 - 40 HP
Mounted Disc Harrow - FKDHUF-14D
Working Width
1635 mm
Working Depth
150 mm
Weight
360 kg
gang bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
40 - 50 HP
Mounted Disc Harrow - FKDHUF-16D
Working Width
1835 mm
Working Depth
150 mm
Weight
400 kg
gang bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
50 - 60 HP
Mounted Disc Harrow - FKDHUF-18D
Working Width
2068 mm
Working Depth
150 mm
Weight
500 kg
gang bolt
32 mm (Solid Square Rod)
Type of Disc
Plain Disc / Notched in Front (Optional)
Disc Diameter
560 mm
Distance Between Discs
228 mm
Tractor HP
60 - 75 HP
