Farmking Hydraulic Disc Harrow Technical Specifications
Farmking Hydraulic Disc Harrow Features
Brand
Model
Hydraulic Disc Harrow
Category
Working Width
2300-3100 mm
No. of Discs
20 to 28
Type
Weight
1500-1830 Kg
Suitable HP
80-165 HP
Gang Bolt
32 mm (Solid Square Rod)
Type of Disc
Plain disc in Rear gang & Notched disc in front
Disc Diameter
610-660 mm
Distance Between Discs
228 mm
Bearing Hub
8
Price
Data Last Updated On: 28 Jul 2026
About Farmking Hydraulic Disc Harrow
Farmking Hydraulic Disc Harrow Models
| Specification | FKHDH-20D | FKHDH-24D | FKHDH-28D |
|---|---|---|---|
| Working Width | 2300 mm | 2700 mm | 3100 mm |
| Weight | 1500 kg | 1660 kg | 1830 kg |
| gang bolt | 32 mm (Solid Square Rod) / Split Gang | 32 mm (Solid Square Rod) / Split Gang | 32 mm (Solid Square Rod) / Split Gang |
| No. of Disc | 20 | 24 | 28 |
| Type of Disc | Plain Disc in Rear Gang & Notched Disc in Front | Plain Disc in Rear Gang & Notched Disc in Front | Plain Disc in Rear Gang & Notched Disc in Front |
| Disc Diameter | 610 mm | 610 mm | 610 mm |
| Distance Between Discs | 228 mm | 228 mm | 228 mm |
| Bearing Hub | 8 | 8 | 8 |
| Width of Cut | 2100 - 3120 mm | 2100 - 3120 mm | 2100 - 3120 mm |
| Tractor HP | 80 - 90 HP | 110 - 135 HP | 140 - 165 HP |
Hydraulic Disc Harrow - FKHDH-20D
Working Width
2300 mm
Weight
1500 kg
gang bolt
32 mm (Solid Square Rod) / Split Gang
No. of Disc
20
Type of Disc
Plain Disc in Rear Gang & Notched Disc in Front
Disc Diameter
610 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2100 - 3120 mm
Tractor HP
80 - 90 HP
Hydraulic Disc Harrow - FKHDH-24D
Working Width
2700 mm
Weight
1660 kg
gang bolt
32 mm (Solid Square Rod) / Split Gang
No. of Disc
24
Type of Disc
Plain Disc in Rear Gang & Notched Disc in Front
Disc Diameter
610 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2100 - 3120 mm
Tractor HP
110 - 135 HP
Hydraulic Disc Harrow - FKHDH-28D
Working Width
3100 mm
Weight
1830 kg
gang bolt
32 mm (Solid Square Rod) / Split Gang
No. of Disc
28
Type of Disc
Plain Disc in Rear Gang & Notched Disc in Front
Disc Diameter
610 mm
Distance Between Discs
228 mm
Bearing Hub
8
Width of Cut
2100 - 3120 mm
Tractor HP
140 - 165 HP
